ALUMINUM OVAL SLEEVES CRIMPERS

Manual crimpers for aluminum oval sleeves and automotive battery connectors crimping

Model No.: HS-14 (With wire cut) Model No.: HS-25
For aluminum oval sleeve For copper tube connector
Chrome-molybdenum alloy steel dies Crimping Range:
Crimping Range: 3/16”
1/16” and 3/32” and 1/8” Tool weight: 2kg
Tool weight: 0.92kg Tool length: 700mm
Tool length: 350mm

Model No.: HS-20
Model No.: HS-24 (With wire cut) For copper tube connector
For aluminum oval sleeve Crimping Range:
Chrome-molybdenum alloy steel dies 1/8” and 3/16”
Crimping Range: Tool weight: 2.3kg
1/16” and 5/64” and 3/32” Tool length: 600mm
7/64” and 1/8” and 5/32” and 3/16“
Tool weight: 2.5kg
Tool length: 600mm

Model No.: HS-16B
For continues connectors
Crimping Range: 10/16mm 2
Tool weight: 2.5kg Tool length: 540mm
For non-insulated and
insulated cable lugs
Oval shape crimping

Model No.: HS-35C
Crimping Range: Model No.: HS-10B
Non-insulated DIN: 16/25/35/50mm AWG 6-1/0 For automotive battery connectors
2
Insulated DIN: 10/16/25/35mm 2 AWG 8-2 Crimping Range:
Tool weight: 2.5kg 10mm / AWG 8
2
Tool length: 600mm Tool weight: 2.5kg
Tool length: 540mm

Model No.: HS-10
(With wire cut) Model No.: HS-35B
For aluminum oval sleeve For automotive battery connectors
Chrome-vanadium steel dies Crimping Range:
2
Crimping Range: JIS: 14-36mm 2
0.5-1mm DIN: 16-35mm
1.5-2mm AWG: 6-2
2.2mm Tool weight: 2.5kg
Tool weight: 0.42kg Tool length: 540mm
Tool length: 150mm

44
