High Leverage Concreters’

Nippers
high lever transmission
99 10 250
► Fast, reliable and economical

► 25 % less effort required compared to conventional
concreters' nippers of the same size
► Extra-slim form for tying deep mounted steel rods

► High-leverage joint, minimising strain, even when 99 10 300
thick binding wires are used

> The high damping of the cutting stroke on cutting through the binding
wire reduces the strain on tendons and muscles
> Cutting edges additionally hardened; cutting edge hardness approx.
61 HRC 99 11 250
> To lace concrete reinforcing steel with binding wire from a roll
> Wire is twisted and cut in a single pass
> High-grade special tool steel, forged, multi stage oil-hardened
> DIN ISO 9242

99 14 250

Cutting capacities
EAN Head width (W3)
Article No. 4003773- mm Pliers Head Handles Ø mm Ø mm Ø mm g
99 10 250 071396 250 3.3 1.8 25.0 350
99 10 300 022398 300 black atramentized polished 3.8 2.0 25.0 501
99 11 250 071402 250 black atramentized polished plastic coated 3.3 1.8 25.0 429
99 11 300 042365 300 3.8 2.0 25.0 537
99 14 250 071419 250 3.3 1.8 25.0 350
99 14 300 028116 300 bright zinc plated 3.8 2.0 25.0 505

CARPENTERS‘ PINCERS AND CONCRETERS‘ NIPPERS I 089
