Hexagon Sockets

for hexagonal socket screws

for internal square 3/8" or 1/2"
> For metric internal hexagonal head screws 98 39 06
> Basic tool chrome-plated
> Special tool steel
> DIN 7422, DIN EN 60900, IEC 60900

EAN Width across flats S Length of non-insulated blade ± 2 Square drive
Article No. 4003773- mm mm mm Inch g
98 39 05 020776 75 5.0 9.0 3/8 59
98 39 06 020783 75 6.0 10.0 3/8 58
98 39 08 020790 75 8.0 11.0 3/8 71
98 49 05 021155 75 5.0 9.0 1/2 68
98 49 06 021162 75 6.0 10.0 1/2 72
98 49 08 021179 75 8.0 11.0 1/2 87

Reversible Ratchet

with driving square 1/2"

> Reversible for clockwise and anti-clockwise directions
> Very reliable retention of the actuating tools ensured
by mechanically locked retaining system
> Chrome vanadium steel
> ISO 3315, DIN EN 60900, IEC 60900 98 42

EAN Square drive
Article No. 4003773- mm Inch g
98 42 026525 265 1/2 599

Torque Wrenches

with driving square, reversible

> Reversible for tightening of lefthanded threads
> Lockable torque adjustment
> Adjustable in steps of 0.25 Nm 98 33 25
> Easy and secure locking of attached sockets due to screw lock
> Calibration certificate included
> Transparent insulated scale range
> Chrome vanadium steel
> ISO 3315, DIN EN 60900, IEC 60900

98 43 50

EAN Range of torsional moment Square drive
Article No. 4003773- mm Nm Inch g
98 33 25 072676 290 5 – 25 Nm 3/8 1230
98 33 50 071761 385 5 – 50 Nm 3/8 1200
98 43 50 071778 385 5 – 50 Nm 1/2 1185

250 I INSULATED TOOLS
