Hand tools Hand tools

1 Range of sockets 1 Range of sockets

863-Bit 1/4″ Reversible ratchet for Wear? – No problem!
screwdriver bits ∙ fine-tooth
• HAZET tools are manufactured to the highest
quality. During long intensive loading there is a
Made in Germany E / certain level of wear even for high‑quality tools.
• A lot more power than with ratchets with the same dimensions
• For this reason, there are spare parts and
replacement sets available for many of our tools.
• Latching function of the shift lever provides protection against unwanted switching
• Increased service life thanks to the use of state-of-
the-art lubricants in the ratchet mechanism Please also see our spare parts shop
• Strict production tolerances prevent dirt from getting in www.hazet.de/ersatzteil-shop
• HAZET internal quality standards guarantee loading
capacity far beyond the standard requirements Cost-saving – Sustainable – Resource-saving!
• Chrome-plated surface: High-quality, easy to clean, corrosion resistant For long-term pleasure with your HAZET tools
• Integrated suspension option in the handle
• VPA tested, static torque according to DIN 3122: 120 Nm (DIN: 62 Nm)
• Number of teeth: 90 (Opening angle 4°)
• With locking spring to securely hold the bits
• HAZET 2-component handle 863 Replacement set
• Surface: chrome-plated
1 ⁄4 Made in Germany

1 4
• Replacement set for shift lever consisting of:
shift lever ∙ pawl ∙ screws ∙ ball ∙ compression spring
For HAZET reversible ratchet 863K ∙ 863 ∙ 863G ∙
863P ∙ 863PC ∙ 863Q ∙ 863S ∙ 863ST ∙ 863BGL ∙
863BKC ∙ 863BK ∙ 863MC ∙ 863Mbit ∙ 2264
863 P/6 144600
1
• Replacement set for ratchet wheel 6.3 = ⁄4″ i consisting of:
ratchet wheel ∙ pawl ∙ shift lever ∙ screws ∙ ball ∙ compression spring
For HAZET reversible ratchet 863G ∙ 863P ∙ 863PC ∙
863ST ∙ 863K ∙ 863MC
1 K 4 863 P/7 N 038596
1
863 HP B 116 235346 • Replacement set for ratchet wheel with safety lock 6.3 = ⁄4″ i consisting of:
Ratchet wheel with safety lock ∙ pawl ∙ shift lever ∙ screws ∙ ball ∙
compression spring
1/4″ Reversible ratchet ∙ For HAZET reversible ratchets 863Q ∙ 863S as well
863-Bit as for retrofitting HAZET reversible ratchets 863P ∙
solid steel ∙ for bits 863PC ∙ 863G ∙ 863ST ∙ 863K ∙ 863MC
Made in Germany E 863 S/7 048472
• 90 mm short design • Replacement set for ratchet wheel 6.3 = ⁄4″ i consisting of:
1
pawl ∙ compression spring ∙ ball ∙ spring sleeve ∙ shift lever ∙ cover disc ∙ circlip ∙
• Number of teeth: 60 (Opening angle 6°) ratchet wheel ∙ grease ∙ assembly tool
• With locking spring to securely hold the bits For reversible ratchet 863HP
• Surface: chrome-plated 863 HP/11 234875
1
• Replacement set for ratchet wheel with safety lock 6.3 = ⁄4″ i consisting of:
assembly tool ∙ cover plate ∙ ratchet wheel with safety lock ∙ circlip ∙ cover
disc ∙ shift lever ∙ spring sleeve ∙ ball ∙ compression spring ∙ pawl ∙ grease
For HAZET reversible ratchet 863HPS as well as for retrofitting HAZET
reversible ratchet 863HP (reduction to maximum 100Nm peak load)
863 HP S/11 241262
• Replacement set for bit ratchet wheel h 6.3 = ⁄4” consisting of:
1
1 K 4 assembly tool ∙ cover plate ∙ bit ratchet wheel ∙ circlip ∙ cover disc ∙ shift lever ∙
863 MB 90 212187 spring sleeve ∙ ball ∙ compression spring ∙ pawl ∙ grease
For reversible ratchet 863HPB
863 HP B/11 241279
• Replacement set for ratchet wheel h 6.3 = ⁄4″ consisting of:
1
ratchet wheel ∙ pawl ∙ shift lever ∙ screws ∙ ball ∙ compression spring
For HAZET reversible ratchet 863BGL ∙ 863BKC ∙ 863BK ∙ 863MBit ∙ 2264
2264/7 015917
866 U 1/4″ Spin type speeder
Made in Germany 1
• With locking ball
• HAZET 2-component handle
• Surface: matt chrome-plated
• DIN 3122, ISO 3315

1 K 4
866 U 134 056453
