包装 套装内含 数量 [g]
ATHH.JS5 架子 ATHH.5,5X100 - 6,5X125 - 8X150 - 10X175 - 12X200 5 952
ATHH.5,5X100 - ATHH.6,5X125 -ATHH. 8X150 - ATHH.10X175 -
AJT.2 盒子 8 908
ATHH.P1 - ATHH.P2 - ATHH.D1 - ATHH.D2

d1
d
Phillips [No] [mm] d [mm] d1 x L1 [mm] L [mm] L2 [mm] [g]
ATHH.P1 PH1 8 25 5 x 100 200 100 60
ATHH.P2 PH2 10 26 6 x 125 235 110 92
ATHH.P3 PH3 13 28 8 x 150 270 120 160

d1
d
Pozidriv [No] [mm] d [mm] d1 x L1 [mm] L [mm] L2 [mm] [g]
ATHH.D1 PZ1 8 25 5 x 100 200 100 60
ATHH.D2 PZ2 10 26 6 x 125 240 115 92
ATHH.D3 PZ3 13 28 8 x 150 270 120 160

d1
E
d
A
A [mm] E [mm] [mm] d [mm] d1 x L1 [mm] L [mm] L2 [mm] [g]
ATHH.4X90 4,0 0,8 6 25 4,5 x 90 195 95 49
ATHH.5.5X100 5,5 1,0 8 25 5,5 x 100 200 100 58
ATHH.6.5X125 6,5 1,2 10 26 6,5 x 125 240 115 99
ATHH.6.5X175 6,5 1,2 10 26 6,5 x 175 290 115 110
ATHH.8X150 8,0 1,2 13 28 8,0 x 150 270 120 160
ATHH.10X175 10,0 1,6 13 30 9,0 x 175 300 125 207
ATHH.12X200 12,0 2,0 17 32 10,0 x 200 330 130 278
ATHH.14X250 14,0 2,5 17 32 10,0 x 250 385 135 331
