Hydraulic Crimpers






               902-484    QuikCrimp

             • 6 Ton Capacity-not to be used with 12 ton-dies.
             • Description: Battery Powered Hex Crimping Tool with die sets.                  Comes
             • Application: Micro computer control system-automatically detects pressure   W/2 Batteries
              when crimping, with double safety protection. Pressure released automatic                                   HYDRAULIC PUNCHES
              Function-tool. The tool is equipped with a double piston which is characterized
              by a fast approach towards the connector material, then a transfer to high
              pressure automatically by slower crimping. Crimping head can be smoothly
              turned by 350°around the longitudinal axis in order to gain better access to
              tight corners and other difficult working areas.
             • Accepts industry standard 6 Ton dies.
             • Packaging: Blow-molded case.

              REPLACEMENTS (INCLUDED IN KIT):
              902-484-DIE-AWG6         Replacement Die - AWG6
              902-484-DIE-AWG4         Replacement Die - AWG4
              902-484-DIE-AWG2         Replacement Die - AWG2
              902-484-DIE-AWG1-0       Replacement Die - AWG1/0
              902-484-DIE-AWG2-0       Replacement Die - AWG2/0
              902-484-DIE-AWG3-0       Replacement Die - AWG3/0
              902-484-DIE-AWG4-0       Replacement Die - AWG4/0
              902-484-DIE-300MCM       Replacement Die - 300MCM
              902-484-DIE-350MCM       Replacement Die - 350MCM
              902-484-DIE-500MCM       Replacement Die - 500MCM
              902-484-DIE-600MCM       Replacement Die - 600MCM
              902-484-BATTERY          Replacement Battery
              902-484-CHARGER          Replacement Battery Charger

               902-480     TuffCrimp 400
             • Description: Hydraulic Crimping Tool - 12 Ton with interchangeable die.
             • Application: Type C head with Interchangeable dies. Crimping head can
              rotate 360˚ Built-in safety valve will by-pass the oil supply when maximum
              pressure is reached. Automatic pressure release. Manual retract after crimping.
             • Accepts industry standard 6 and 12 ton dies.







              REPLACEMENTS (INCLUDED IN KIT):
              902-480-DIE-AWG6         Replacement Die - AWG6
              902-480-DIE-AWG4         Replacement Die - AWG4
              902-480-DIE-AWG2         Replacement Die - AWG2
              902-480-DIE-AWG1-0       Replacement Die - AWG1/0
              902-480-DIE-AWG2-0       Replacement Die - AWG2/0
              902-480-DIE-AWG3-0       Replacement Die - AWG3/0
              902-480-DIE-AWG4-0       Replacement Die - AWG4/0
              902-480-DIE-300MCM       Replacement Die - 300MCM
              902-480-DIE-350MCM       Replacement Die - 350MCM
              902-480-DIE-500MCM       Replacement Die - 500MCM
              902-480-DIE-600MCM       Replacement Die - 600MCM                  Tuff
              902-480-DIE-800MCM       Replacement Die - 800MCM                          Crimp 400
