900-247 Round Hole Bread Board

• 840 tie points
• Round hole designed for easy plug and pull
• Expandable by combining several boards
together to meet your different requirement
• Wearproof material made of ABS & phosphor bronze with
good flexibility and electric conductivity
64mm/
2.5" SOLDERING / ASSEMBLY

171mm/
Individual packing 840 tie points 6.7"
Excellent expandability Friendly graduations Blister card

900-248/900-249 Round Hole Bread Board

Application:
Used as a simulated layout for R&D and students.
Features:
• Round hole designed for easy plug and pull
• Expandable by combining several boards
together to meet your different requirement
• Wearproof material made of ABS & phoshor bronze 243mm
with good flexibility and electric conductivity 9.6"

175mm
6.9"

188mm
7.4" 183mm
Edge plate can easily fold up 7.2"
900-248 1580 tie points 900-249 2420 tie points
(Demo only)
Model No. Tie points Individual packing (Demo only)
900-248 1580 Blister card TAIWAN PATENT NO. 215526
900-249 2420 CHINA PATENT ZL 03231122.2

900-271/900-272 Bread Board Accessory

• 70 pcs of 22 AWG solid wires • 350pcs of 22 AWG solid wires
• Pre-cut, pre stripped and pre-formed on each end • Pre-cut, pre stripped and pre-formed on each end
• Variety of colors • Variety of colors
• Completely reusable • Completely reusable
• 14 lengths x 5 pcs each • 14 lengths x 25 pcs each
• (2, 5, 7, 10, 12, 15, 17, 20, 22, 25, 50, 75, 100 and 125mm) • (2, 5, 7, 10, 12, 15, 17, 20, 22, 25, 50, 75, 100 and 125mm)

• This kit contains specialized tools you need for soldering;
a heat sink to protect your heat-sensitive devices, knife
and brush, scraper and hook, fork and spike.

900-271 900-272

Case Size (mm/inch) Individual packing Case Size (mm/inch) Individual packing
165x55x15/ 6.5x2.2x0.6 Poly bag + Hanger 178x90x28/ 7x3.5x1.1 Poly bag + Hanger
